Please refer to our Min/Max Part Size chart for each material before customizing.
Available services are dependent on part size and material. Please see our Processing Min/Max chart prior to customizing.
When choosing templates for laser cutting, it’s essential to consider your project’s requirements and your desired outcome. Look for templates that align with your design aesthetic and suit the material you plan to use. Consider factors like complexity, scalability, and customization options. By carefully selecting templates, you can ensure a smooth and successful laser cutting experience, bringing your creative visions to life with precision and efficiency.
We proudly use hardware by PEM
|Thread Size||4-40 x .250″|
|Hole size in sheet (+0.003/-.0.000)||.168″|
|Minimum sheet thickness||0.040″|
|Maximum sheet thickness||.125″|
|Minimum distance hole C/L to edge||0.230″|
|When determining the distance between two or more fasteners, you can calculate the distance by the formula, C/L to edge + 1/2 the diameter of the second mounting hole.||.314″|
|Recommended panel material||Steel/Aluminum|
|Aluminum material ranges (5052, 6061, 7075)||0.040″-0.125″|
|Steel material ranges (CRS, HRPO, HR)||0.048″-0.119″|
