In chapter 5 lesson 5, Jake dives into the two key calculations behind sheet metal bending: bend allowance and bend deduction. These formulas explain how metal stretches and compresses during bending and help you predict the final size of your parts accurately.
Jake revisits terms from the previous lesson, like bend radius, K-factor, and material thickness, and shows how each affects your part’s elongation and final flange length. He explains that bend allowance measures the true length of the material along the bend after forming, while bend deduction determines how much to remove from your flat pattern so the finished part bends to the correct dimensions.
He emphasizes that errors in these calculations can lead to incorrect flange lengths, hole misalignment, and parts that don’t fit as intended. Understanding and applying these relationships ensures that your bent parts match your CAD model in the real world.
What You’ll Learn:
Additional resources:
Bending Guidelines
Bend Calculator
