Flush Standoff, 4-40, .250" Zinc plus Clear Chromate

SKU SO-440-8
Thread Size 4-40 x .250″
Hole size in sheet (+0.003/-.0.000) .168″
Minimum sheet thickness 0.040″
Maximum sheet thickness .125″
Fastener material Steel
Minimum distance hole C/L to edge 0.230″
When determining the distance between two or more fasteners, you can calculate the distance by the formula, C/L to edge + 1/2 the diameter of the second mounting hole. .345″
Recommended panel material Steel/Aluminum
Coating type Zinc
Length .250″
Aluminum material ranges (5052, 6061, 7075) 0.040″-0.125″
Steel material ranges (CRS, HRPO, HR) 0.048″-0.119″
